Below is the detailed specification for the 15.6" Optimus IV.
| Dimensions & Weight | | Dimensions (W x D x H) | 374mm x 250mm x 16.3~42.7mm | | Weight | 2.7Kg including ODD and battery | | Chipset | | Chipset | Mobile Intel ® HM77 Express Chipset | | Processor Support | Supports Sandy Bridge & Ivy Bridge CPUs | | Memory | | Memory Type | Supports DDR-III 1333MHz (1600MHz with Core i7) | | Number of Modules | 3 | | Maximum Supported Memory | 24GB | | Hard Drive Capacity | | Hard Drive Type | 2 x 9.5mm 2.5" S-ATA Hard Drive Support | | Display & Graphics | | Graphics | 2GB GeForce™ GTX 660M | | Screen Size | 15.6 inch Widescreen | | Native/Maximum Resolution | 1920 x 1080 | | Backlight | LED | | Nvidia® Optimus™ Technology | Yes | | Audio | | Chipset | Intel High Definition Audio | | Channels | 2 channel HD Audio | | Connections | Audio Jack Stereo x 1 (Line in / Line out) / SPDIF | | Speakers | 2 x Onkyo High Quality Speakers | | Integrated Microphone | Yes | | Communications | | LAN | Gigabit LAN | | Wireless Support | Wireless LAN 802.11B/G/N Half Mini Card module | | Bluetooth Support | Bluetooth V4.0 module support | | Webcam | 1.3MP Webcam | | Firewire (IEEE 1394) | N/A | | Expansion Slots | | PCI Express Card | N/A | | TV Tuner | N/A | | Keyboard & Mouse | | Keys | Full size isolated keyboard with numeric pad | | Language Support | Multi-Language support | | Pointing Device | Touchpad Mouse | Built in touch pad with multi-gesture and scrolling function | | Memory Card Reader | | Memory Card Reader | 9-in-1 Card Reader | | Ports | | HDMI Ports | 1 | | USB | 3 x USB 3.0 Ports & 1 x USB 2.0 Port | | USB/e-SATA | 1 | | Display | 1 x 15 pin VGA OUT port | | Microphone-IN | 1 | | Headphone-OUT | 1 | | DC-in | 1 | | LAN | 1 x RJ-45 jack | | S/PDIF | 1 x S/PDIF Out | | Kensington Lock | Yes | | Optical OUT | 1 | | Webcam | | Webcam | 1.3MP Webcam | | Battery & Power Lead | | Battery Type | 8 Cell Smart Lithium-ION Battery Pack - 76.96WH | | Typical Battery Life | Up to 6 hours in UMA mode | | Power Lead & AC Adpater | 1 x Power Lead included with AC Adapter | | Security | | Fingerprint Scanner | N/A | | Kensington Lock | Yes |
|
Breeze through your daily work, enjoy playing the latest games, or watch the latest blu-ray movies on this dazzling 15.6 inch full HD screen. The stylish 15.6" Optimus IV features a brushed aluminium effect and nVIDIA Optiums Technology, which switches your graphics between the onboard gpu or nVIDIA® GeForce® GT 660M automatically for extra performance or increased battery life, or you can press the Optimus switchable graphic button which will keep internal graphic on all the way. The Optimus provides you with an amazing experience whether your working, playing or relaxing.
The 15.6" Optimus IV is packed full of features, some of which include the following:
| 3rd Gen Intel® Core™ CPUs |  | Enjoy brilliant imagery and a seamless computing experience
The visibly smart Intel® Core™ processor family provides incredible performance and stunning visuals delivered by a range of Intel® technologies. Enjoy brilliant imagery and a seamless computing experience—whether you're creating, sharing, exploring, or gaming.
Choose the right processor for your computing needs from the Intel® Core™ processor family and get ready to thrill and astonish yourself. Because the only thing more amazing than Intel® technology is what you'll do with it. | | 2GB GeForce™ GTX 660M |  | Gear up with NVIDIA GeForce GTX 660M dedicated graphics for double your gaming performance and extra long battery life with NVIDIA® Optimus™ technology. Get equipped with the very best in gaming tech, like NVIDIA® PhysX® technology, and immerse yourself with NVIDIA® 3D Vision® - the #1 3D technology for notebooks. | | Full HD 1920 x 1080 Res |  | With a 1920 x 1080 resolution you can be confident that your screen can display higher resolution images with better clarity and reduce the need for horizontal scrolling.
Supporting full HD, watching BluRay movies while on the move just became a lot easier!
For those who use their computer for business, a 1920 x 1080 resolution is the best choice for working with high resolution images, and for the mobile gamers out there a 1920 x 1080 resolution will set you up to get more frags than your enemies! | | NVIDIA® Optimus™ |  | GREAT BATTERY LIFE AND GREAT PERFORMANCE. IT'S THAT SIMPLE.
NVIDIA® Optimus™ technology intelligently optimizes your notebook PC, providing the outstanding graphics performance you need, when you need it, all the while extending battery life for longer enjoyment.
Key Benefits:
- Optimus technology is completely automatic allowing you to experience longer battery life and amazing visuals without having to manually change settings.
- Behind the scenes and with no interference to what you're doing, Optimus seamlessly figures out how to best optimize your notebook computing experience.
- NVIDIA graphics you've come to expect, with more than 10x better performance with NVIDIA® CUDA™ technology, allowing you to enjoy your applications and games without interruption or worry.
| | SuperSpeed USB 3.0 |  | With transfer speeds of 480Mbps USB 3.0 offers upto 40 times greater bandwith than pervious USB formats such as 1.1. The best thing about it is that USB 3.0 is backwards compatible, so even though there are few devices out there at the moment which will use the full potential of USB 3.0, your USB 2.0 devices will still benefit from faster transfer speeds. | | Premium Onkyo Speakers |  | ONKYO is an organization consisting of people unsurpassed in the love of sound. For the past half century ONKYO components have been recognised as uncommonly musical among those who are truly fanatical about their music.
Having ONKYO speakers integrated inside your notebook computer will give you the very best sound that can be produced by small speakers packed into the confinements of a notebook! | | HDMI Output Connection |  | Connecting your computer to your HD devices just got easier! With the built in HDMI OUT port, you can stream your images and videos straight to your HD device, such as your flat screen TV or HD monitor for ultimate clarity when playing games or video editing! | | 1.3MP Webcam |  | With an integrated webcam as standard, there is no time lost in connecting external webcams and no extra weight and messy wires to carry around.
Great for keeping up appearances with your friends & family, or alternatively a nice feature which will allow you to video conference with your colleagues while you're on the move! | | Killer Wireless-N Option Available |  | Killer Wireless-N high-performance wireless networking adapters have exclusive Killer Wireless Technology, combining intelligence and control along with up to five times the wireless networking speed of competitive wireless adapters. The Killer Wireless-N family includes Advanced Stream Detect™ technology to automatically classify and prioritize latency-sensitive network traffic for online games, HD video and high-quality audio to maximize your online experience.
Killer Wireless-N adapters support dual band (2.4 GHz and 5GHz), 2-stream MIMO and IEEE standards-based 802.11a/b/g/n in a half-size mini-PCIe form factor. Killer Wireless-N adapters offer industry-leading data rates (up to 300 Mbps) with range-enhancing 802.11n technologies to deliver faster wireless throughput over longer distances. Killer Wireless-N adapters also feature reduced power consumption and Wi-Fi Direct™ peer-to-peer technology to ensure maximum flexibility for mobile gamers. | | BluRay Capable |  | Having powerful graphics, your computer can support the playback of BluRay discs providing you select a BluRay player/writer when configuring your computer.
Alternatively, you have the peace of mind in knowing that you can upgrade your drive to a BluRay player at a later date! | | FREE 90 Day Trial of BullGuard Internet Security |  | BullGuard Internet Security 9.0 has all the technical stuff tucked away beneath a very simple user interface. It offers comprehensive protection from viruses and all other online threats, including 5 GB online backup. The Game Mode and 3-PC licence makes it the perfect household security suite. | | Wireless Fitted as Standard |  | More and more technologies are taking advantage of wireless facilities, so it wouldn't be wise to purchase a new computer without a wireless facility.
Using our configurator you can choose from a basic 802.11N wireless connection or you also have the option to upgrade to faster models to give you the greatest bandwidth for your games and applications. | | Bluetooth Option Available |  | Bluetooth™ is a technology that lets Bluetooth™ enabled devices, such as your mobile phone for example, connect to each other to transfer data and files.
Having a Bluetooth™ adapter integrated into your computer saves connecting external USB dongles, which can often become lost or broken. | | VGA Output Connection |  | Also included is a VGA port, which will allow you to connect your computer to a second display device, such as a computer monitor, TV or projector.
Ideal for turning your computer into a dual screen station when docking at home at in the office! | | e-SATA Input Connection |  | For those who need lots of storage space or regurarly like to backup their files, an e-SATA port saves time and increases transfer speeds over conventional USB ports.
You can also use your e-SATA port to boot from different external hard drives depending on whether your at home or in the office, turning your computer into a business machine and a home computer in one! |
|
